C002332_15_CR3_User_Manual 49

Save Settings

4.3 - Laser Settings

Scan one of the following codes to set the brightness of the CR3 laser.

High (Default) Medium Low

Scan the following codes to turn laser targeting on/off:

On (Default) Off

4.4 - Reader Power Off Settings

Scan the following codes to set the amount of time before a reader powers off:

1 Hour 2 Hours - Default 4 Hours
