C002332_15_CR3_User_Manual 34

Save Settings

2.4 - Left Trigger Programming

Left Trigger Take Picture

Note: If you program a trigger to another function, you will need to reset any performance code settings.

2.6 - Right Trigger Programming

Right Trigger Take Picture

Note: If you program a trigger to another function, you will need to reset any performance code settings.

2.5 - Right Trigger Optimization Matrix

Both

Fields

Far

Field

SXGA

Near

Field
